a anic so ation in and App ications

sion. The products are ideal for the main inverter
systems in automotive applications, in which
effi ciency, space savings, and monitoring functions
are mandatory requirements, according to Infi neon.
The EiceDRI ER offers stable operation in harsh
EMC environments and drives up to 100-A 1,200-
IGBTs with its integrated 2-A output stage. Collec-
tor-emitter saturation voltage ( CE(sat) ) detection
and active Miller clamp features complete the
layout of this IGBT driver IC family.
Infi neon’s 2ED020I12FA E ALKIT, shown
in Figure 2, is an evaluation board for the
2ED020I12FA dual-channel isolated IGBT driver for
600- 1,200- IGBTs. The board allows designers
to accelerate the development phase of critical
automotive projects, evaluating the functionalities
offered by the EiceDRI ER device family.
Figure 2: The 2ED020I12FA evaluation kit mage n neon Galvanic isolation has two main objectives func-
tionality and safety. From a functional perspective,
it allows the signal transmission (master) circuits
motors and DC/DC converters. The reference platform, whose typical to operate separately from the acquisition (slave) circuits, thereby
application is shown in Figure 1, includes up to four boards based on allowing independent voltage references and preventing the formation
multicore 2-bit MCUs, an advanced Motor Control Timing software of noise-generating ground loops. From a safety perspective, it protects
library, and interconnect cabling. The reference design can effi ciently circuits and people from high voltages between the input and output cir-
drive a 100-kW three-phase motor from a 00- supply with integrated cuits that can result from failures or overvoltages of atmospheric origin.
galvanic signal isolation in insulated-gate bipolar transistor (IGBT) Clearly, then, galvanic isolation is a critical aspect of E E design. ■
gate drivers.
Infi neon’s EiceDRI ER single- and dual-channel automotive IGBT Maurizio Di Paolo Emilio is a staff correspondent at AspenCore
driver ICs provide galvanic isolation and bidirectional signal transmis- editor o o er ectronics e s and editor in c ie o e .
