36 EE|Times EUROPE

           Wide-Bandgap Semiconductors: The Next Wave of GaN and SiC


             With the full portfolio, designers don’t have   itation when you get to the larger wafer sizes,   and lower cost that will benefit the overall
           to make large compromises in optimizing   which means you won’t be able to get as many   industry, he added. ■
           their system for efficiency, cost, or thermal   wafers per batch, he said.
           management, Losee said.               There is room for a lot of innovation in   Gina Roos is editor-in-chief of Electronic
             X-trinsic’s Rhoades took a step upstream to   manufacturing methods to drive higher yield   Products.
           discuss SiC wafering and the process sequence
           (and challenges) in the task of turning a single
           crystal puck of SiC into device-ready wafers.
             SiC is unique in that it is an extremely
           hard crystal and is also chemically inert,   Conference Proceedings Ebook
           which makes it difficult to take through the
           sequence steps.                        Power electronics is playing an increasingly important
             “You have to redevelop these processes   role in automotive, industrial, and consumer markets.
           with the properties of silicon carbide in mind,   It is an enabling technology for a wide range of
           and each step will take longer and it will likely   new functions that enhance vehicle and smart-grid
           be more expensive,” said Rhoades.      performance, safety, and functionality. Power devices
             As an example, “a lot of folks are now using   will improve system performance in energy-saving
           slurries that are formulated around potassium   applications as well as in all high-voltage industrial
           and permanganate,” he said. “That is one of   applications. At the recent PowerUP Expo virtual
           the innovations that has enabled SiC to now   conference and exhibition, industry luminaries and
           be available in reasonable quantities, and of
           course, everyone wants to reduce cost.”  technology experts helped us envision the future of
                                                  power electronics.
           INFLECTION POINT                         The conference proceedings ebook condenses the
           Rhoades noted an inflection point occurring   information offered in the event’s keynotes, panel
           at 200 mm, with a transition to single-wafer   discussions, and technical presentations. It also provides links to
           processing. In the 100-mm to 150-mm wafer   video recordings of the keynotes, technical presentations and panel
           sizes, the traditional process sequence has   discussions, and slide decks.
           involved batch polishing and batch lapping at   Visit bit.ly/3oCmd9H to download the ebook.
           the wafer-polishing and -shaping steps, and
           those are starting to show a geometric lim-





            POWERING THE FUTURE
           ‘AspenCore Guide to Silicon Carbide’: New Book

           Explores SiC in Smart-Energy Era


           By Maurizio Di Paolo Emilio and Nitin Dahad


                egardless of your target application, if you’re working on elec-  silicon-only equivalents. Robustness and greater dependability are
                tronics design and development today, you can’t afford to treat   other important attributes, resulting in higher total device life expec-
                power as an afterthought. “AspenCore Guide to Silicon Carbide:   tancy and operational stability.
          REnabling a Smart Energy Future” is a new resource for navigat-
           ing silicon carbide technology’s expanding role in the industry’s efforts   In the newest AspenCore guide, tech and
           to enable renewable smart power and power conversion efficiency.
           The book, available exclusively from the EE Times Store, provides a   market experts guide engineers and executives
           backgrounder on SiC technology, explaining how and why its electrical   through the process of integrating SiC power
           characteristics are suited to power electronics systems in different
           vertical markets; explores SiC’s practical implementation in devices;   devices into systems and applications.
           and examines its market traction now and its potential as a mainstream
           technology for the future.
             The power electronics sector has been transitioning toward   SiC technology has entered the deployment stage just as the
           wide-bandgap materials as silicon hits its theoretical performance   global drive toward energy sustainability pushes industries to
           limitations for power devices. WBG power semiconductor devices based   deliver cleaner, more efficient electrical power conversion. The auto
           on SiC and gallium nitride technologies provide design advantages   industry’s wholesale shift toward vehicle electrification, driven by
           that allow improved application performance, including low leakage   global CO  emission-reduction objectives, helped kickstart SiC market
                                                                        2
           current, significantly reduced power losses, higher power density,   growth, fueling product development that is expected to move SiC
           higher-frequency operation, and the ability to tolerate higher operating   power devices into broader industrial, electromobility, and
           temperatures, all in a smaller device size than would be possible for    renewable-energy applications.
