EE|Times EUROPE — Boards & Solutions Insert 39
iniat ri e C rrent ensin or cient o er Con ersion ste s

Built-in overcurrent detection (OCD) units separate the control appli-
cation path to the safety loop. With two separate OCD units, the sensor
can monitor overload and short-circuit events simultaneously.
The protection and detection features of the MSR series target
AC or motor-driven applications. For solar-industry applications,
which need to be surge-tolerant to provide adequate lightning protec-
tion, LEM has designed and tested the MSR to deliver the required
performance per the standard 20- s surge test profi le.
LEM provides an MSR evaluation board for quick prototyping and
test (Figure 4).

TAMURA’S L32P SERIES
Tamura produces current sensors based on all- and fl uxgate-effect
technology. The company states that the high accuracy and mechanical
robustness of its open- and closed-loop products make it a world leader Figure 5: Tamura’s lineup (Image: Tamura)
together with LEM and oneywell in all industrial sectors. Driver modules
complete the product range for driving silicon carbide (SiC) MOSFET driven by regulatory and market mandates to improve effi ciency and
IGBT and DC DC isolated converters. safety. The control of these systems requires robust magnetic sensors
Tamura’s solutions feature fast response times high-frequency that can operate reliably in harsh environments. A frequent challenge
operation with minimal internal temperature rise excellent d dt is the presence of common-mode noise and interference, which can
noise immunity magnetic fi eld stability and sulfur-proof options, limit measurement. Wear and tear on the gears can also lead to a
depending on customer application requirements (Figure 5). reduction or loss of control signals.
The company’s L 2PxxxS0 (B)FS series of open-loop sensors The use of all sensors addresses these problems. Sensor performance
uses a ferrite core for PCB mounting design. eat generation due to can be signifi cantly improved by incorporating them into a system and
high-frequency current is reduced with a wide electrical current range leveraging synergistic relationships as feedback and compensation. ■
(saturation current of 1 0 to 600 A).
The use of electronic controls for engine, transmission, and wheel Maurizio Di Paolo Emilio is a staff correspondent at AspenCore
speed control in vehicles and industrial systems continues to rise, editor o o er ectronics e s and editor in c ie o e .
